Resource Profile: Cross-Measure Patient Profile

This profile contains NHSN-specific Required and Must-Support elements for reporting Patient information on public-health surveillance measures to NHSN.

This profile is based on US Core Patient 3.1.1.

NHSN only recognizes the data element 'sex', with male and female as the only accepted responses. These data are mapped from either the patient.extension (birthsex), or patient.gender FHIR standard data elements. These two FHIR standard data elements provide male/female options, per US Core 3.1.1.

For data submitted for patient.gender, and/or patient.extension (birthsex) that do not align with male or female, NHSN will label those responses as not reported. As national standards update, this resource will also be updated.

Usages:

• Use this Profile: NHSN MeasureReport Bundle and NHSN Subject Bundle
• Examples for this Profile: Patient/patient-example-ach-daily-influenzatherapeutic, Patient/patient-example-ach-daily-initialpopulationpass, Patient/patient-example-ach-daily-negativepcr, Patient/patient-example-ach-daily-rsvlabbtg... Show 3 more, Patient/patient-example-ach-monthly-pass1, Patient/patient-example-ach-monthly-pass2 and Patient/patient-example-ach-monthly-pass3

You can also check for usages in the FHIR IG Statistics

Formal Views of Profile Content

Description of Profiles, Differentials, Snapshots and how the different presentations work.

• Key Elements Table
• Differential Table
• Snapshot Table
• Statistics/References
• All

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Patient		0..*	USCorePatientProfile(6.1.0)	Information about an individual or animal receiving health care services
id	Σ	1..1	id	Logical id of this artifact
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
Slices for extension				Content/Rules for all slices
extension:race		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-race
extension:ethnicity		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-ethnicity
extension:tribalAffiliation		0..*	(Complex)	(USCDI) Tribal Affiliation Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-tribal-affiliation
extension:birthsex		0..1	code	Birth Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-birthsex Binding: Birth Sex (required): Code for sex assigned at birth
extension:sex		0..1	code	(USCDI) Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-sex Binding: Sex (required): Concepts limited to Male, Female, Patient Sex Unknown, asked-declined.
extension:genderIdentity		0..*	CodeableConcept	(USCDI) The individual's gender identity URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-genderIdentity Binding: Gender Identity (extensible)
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
identifier	SΣ	1..*	Identifier	(USCDI) An identifier for this patient
use	?!SΣ	0..1	code	usual | official | temp | secondary | old (If known) Binding: IdentifierUse (required): Identifies the purpose for this identifier, if known .
type	SΣ	0..1	CodeableConcept	Description of identifier Binding: Identifier Type Codes (extensible): A coded type for an identifier that can be used to determine which identifier to use for a specific purpose.
system	SΣ	1..1	uri	(USCDI) The namespace for the identifier value Example General: http://www.acme.com/identifiers/patient
value	SΣ	1..1	string	(USCDI) The value that is unique within the system. Example General: 123456
period	SΣ	0..1	Period	Time period when id is/was valid for use
active	?!Σ	0..1	boolean	Whether this patient's record is in active use
name	SΣC	1..*	HumanName	(USCDI) A name associated with the patient Constraints: us-core-6
use	?!SΣ	0..1	code	(USCDI) usual | official | temp | nickname | anonymous | old | maiden Binding: NameUse (required): The use of a human name.
text	SΣ	0..1	string	Text representation of the full name
family	SΣC	0..1	string	(USCDI) Family name (often called 'Surname')
given	SΣC	0..*	string	(USCDI) Given names (not always 'first'). Includes middle names This repeating element order: Given Names appear in the correct order for presenting the name
prefix	SΣ	0..*	string	Parts that come before the name This repeating element order: Prefixes appear in the correct order for presenting the name
suffix	SΣ	0..*	string	(USCDI) Parts that come after the name This repeating element order: Suffixes appear in the correct order for presenting the name
period	SΣ	0..1	Period	(USCDI) Time period when name was/is in use
telecom	Σ	0..*	ContactPoint	(USCDI) A contact detail for the individual
system	SΣC	1..1	code	(USCDI) phone | fax | email | pager | url | sms | other Binding: ContactPointSystem (required): Telecommunications form for contact point.
value	SΣ	1..1	string	(USCDI) The actual contact point details
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | mobile - purpose of this contact point Binding: ContactPointUse (required)
rank	SΣ	0..1	positiveInt	Specify preferred order of use (1 = highest)
period	SΣ	0..1	Period	Time period when the contact point was/is in use
gender	SΣ	1..1	code	(USCDI) male | female | other | unknown Binding: AdministrativeGender (required)
birthDate	SΣ	1..1	date	(USCDI) The date of birth for the individual
deceased[x]	?!SΣ	0..1		(USCDI) Indicates if the individual is deceased or not
deceasedBoolean			boolean
deceasedDateTime			dateTime
address	SΣ	0..*	Address	(USCDI) An address for the individual
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | billing - purpose of this address Binding: AddressUse (required): The use of an address. Example General: home
type	SΣ	0..1	code	postal | physical | both Binding: AddressType (required): The type of an address (physical / postal). Example General: both
text	SΣ	0..1	string	Text representation of the address Example General: 137 Nowhere Street, Erewhon 9132
line	SΣ	0..*	string	(USCDI) Street name, number, direction & P.O. Box etc. This repeating element order: The order in which lines should appear in an address label Example General: 137 Nowhere Street
city	SΣ	0..1	string	(USCDI) Name of city, town etc. Example General: Erewhon
district	SΣ	0..1	string	District name (aka county) Example General: Madison
state	SΣ	0..1	string	(USCDI) Sub-unit of country (abbreviations ok) Binding: UspsTwoLetterAlphabeticCodes (6.1.0) (extensible): Two Letter USPS alphabetic codes.
postalCode	SΣ	0..1	string	(USCDI) US Zip Codes Example General: 9132
country	SΣ	0..1	string	Country (e.g. can be ISO 3166 2 or 3 letter code)
contact	SC	0..*	BackboneElement	A contact party (e.g. guardian, partner, friend) for the patient Constraints: pat-1
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
relationship	S	0..*	CodeableConcept	The kind of relationship Binding: PatientContactRelationship (extensible): The nature of the relationship between a patient and a contact person for that patient.
name	S	0..1	HumanName	A name associated with the contact person
address	S	0..1	Address	Address for the contact person
period	S	0..1	Period	The period during which this contact person or organization is valid to be contacted relating to this patient
communication		0..*	BackboneElement	(USCDI) A language which may be used to communicate with the patient about his or her health
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
language	S	1..1	CodeableConcept	(USCDI) The language which can be used to communicate with the patient about his or her health Binding: LanguageCodesWithLanguageAndOptionallyARegionModifier (6.1.0) (extensible)
preferred	S	0..1	boolean	Language preference indicator
link	?!SΣ	0..*	BackboneElement	Link to another patient resource that concerns the same actual person
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
other	Σ	1..1	Reference(Patient | RelatedPerson)	The other patient or related person resource that the link refers to
reference	ΣC	1..1	string	Literal reference, Relative, internal or absolute URL
type	Σ	1..1	code	replaced-by | replaces | refer | seealso Binding: LinkType (required): The type of link between this patient resource and another patient resource.
Documentation for this format

Terminology Bindings

Path	Conformance	ValueSet	URI
Patient.identifier.use	required	IdentifierUse http://hl7.org/fhir/ValueSet/identifier-use|4.0.1 From the FHIR Standard
Patient.identifier.type	extensible	Identifier Type Codes http://hl7.org/fhir/ValueSet/identifier-type From the FHIR Standard
Patient.name.use	required	NameUse http://hl7.org/fhir/ValueSet/name-use|4.0.1 From the FHIR Standard
Patient.telecom.system	required	ContactPointSystem http://hl7.org/fhir/ValueSet/contact-point-system From the FHIR Standard
Patient.telecom.use	required	ContactPointUse http://hl7.org/fhir/ValueSet/contact-point-use From the FHIR Standard
Patient.gender	required	AdministrativeGender http://hl7.org/fhir/ValueSet/administrative-gender From the FHIR Standard
Patient.address.use	required	AddressUse http://hl7.org/fhir/ValueSet/address-use|4.0.1 From the FHIR Standard
Patient.address.type	required	AddressType http://hl7.org/fhir/ValueSet/address-type|4.0.1 From the FHIR Standard
Patient.address.state	extensible	UspsTwoLetterAlphabeticCodes http://hl7.org/fhir/us/core/ValueSet/us-core-usps-state|6.1.0
Patient.contact.relationship	extensible	PatientContactRelationship http://hl7.org/fhir/ValueSet/patient-contactrelationship From the FHIR Standard
Patient.communication.language	extensible	LanguageCodesWithLanguageAndOptionallyARegionModifier http://hl7.org/fhir/us/core/ValueSet/simple-language|6.1.0
Patient.link.type	required	LinkType http://hl7.org/fhir/ValueSet/link-type|4.0.1 From the FHIR Standard

Constraints

Id	Grade	Path(s)	Details	Requirements
dom-2	error	Patient	If the resource is contained in another resource, it SHALL NOT contain nested Resources : contained.contained.empty()
dom-3	error	Patient	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource : contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Patient	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated : contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Patient	If a resource is contained in another resource, it SHALL NOT have a security label : contained.meta.security.empty()
dom-6	best practice	Patient	A resource should have narrative for robust management : text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children : hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both : extension.exists() != value.exists()
pat-1	error	Patient.contact	SHALL at least contain a contact's details or a reference to an organization : name.exists() or telecom.exists() or address.exists() or organization.exists()
us-core-6	error	Patient.name	At least name.given and/or name.family are present or, if neither is available, the Data Absent Reason Extension is present. : (family.exists() or given.exists()) xor extension.where(url='http://hl7.org/fhir/StructureDefinition/data-absent-reason').exists()

This structure is derived from USCorePatientProfile

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Patient		0..*	USCorePatientProfile(6.1.0)	Information about an individual or animal receiving health care services
id		1..1	id	Logical id of this artifact
meta
Slices for extension				Content/Rules for all slices
extension:link-received-date-extension		0..1	dateTime	Received Date URL: http://www.cdc.gov/nhsn/fhirportal/dqm/ig/StructureDefinition/link-received-date-extension
Slices for extension				Content/Rules for all slices
extension:race		0..1	USCoreRaceExtension(6.1.0)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.)
extension:ethnicity		0..1	USCoreEthnicityExtension(6.1.0)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.)
identifier
use	S	0..1	code	usual | official | temp | secondary | old (If known)
type	S	0..1	CodeableConcept	Description of identifier
period	S	0..1	Period	Time period when id is/was valid for use
name
use	S	0..1	code	(USCDI) usual | official | temp | nickname | anonymous | old | maiden
text	S	0..1	string	Text representation of the full name
prefix	S	0..*	string	Parts that come before the name
suffix	S	0..*	string	(USCDI) Parts that come after the name
period	S	0..1	Period	(USCDI) Time period when name was/is in use
telecom
rank	S	0..1	positiveInt	Specify preferred order of use (1 = highest)
period	S	0..1	Period	Time period when the contact point was/is in use
birthDate		1..1	date	(USCDI) The date of birth for the individual
deceased[x]	S	0..1	boolean, dateTime	(USCDI) Indicates if the individual is deceased or not
address
use	S	0..1	code	(USCDI) home | work | temp | old | billing - purpose of this address
type	S	0..1	code	postal | physical | both
text	S	0..1	string	Text representation of the address
district	S	0..1	string	District name (aka county)
country	S	0..1	string	Country (e.g. can be ISO 3166 2 or 3 letter code)
contact	S	0..*	BackboneElement	A contact party (e.g. guardian, partner, friend) for the patient
relationship	S	0..*	CodeableConcept	The kind of relationship
name	S	0..1	HumanName	A name associated with the contact person
address	S	0..1	Address	Address for the contact person
period	S	0..1	Period	The period during which this contact person or organization is valid to be contacted relating to this patient
communication
preferred	S	0..1	boolean	Language preference indicator
link	S	0..*	BackboneElement	Link to another patient resource that concerns the same actual person
other
reference		1..1	string	Literal reference, Relative, internal or absolute URL
Documentation for this format

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Patient		0..*	USCorePatientProfile(6.1.0)	Information about an individual or animal receiving health care services
id	Σ	1..1	id	Logical id of this artifact
meta	Σ	0..1	Meta	Metadata about the resource
id		0..1	string	Unique id for inter-element referencing
Slices for extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
extension:link-received-date-extension		0..1	dateTime	Received Date URL: http://www.cdc.gov/nhsn/fhirportal/dqm/ig/StructureDefinition/link-received-date-extension
versionId	Σ	0..1	id	Version specific identifier
lastUpdated	Σ	0..1	instant	When the resource version last changed
source	Σ	0..1	uri	Identifies where the resource comes from
profile	Σ	0..*	canonical(StructureDefinition)	Profiles this resource claims to conform to
security	Σ	0..*	Coding	Security Labels applied to this resource Binding: All Security Labels (extensible): Security Labels from the Healthcare Privacy and Security Classification System.
tag	Σ	0..*	Coding	Tags applied to this resource Binding: CommonTags (example): Codes that represent various types of tags, commonly workflow-related; e.g. "Needs review by Dr. Jones".
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
language		0..1	code	Language of the resource content Binding: CommonLanguages (preferred): A human language. Additional Bindings Purpose AllLanguages Max Binding
text		0..1	Narrative	Text summary of the resource, for human interpretation This profile does not constrain the narrative in regard to content, language, or traceability to data elements
contained		0..*	Resource	Contained, inline Resources
Slices for extension		0..*	Extension	Extension Slice: Unordered, Open by value:url
extension:race		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-race
extension:ethnicity		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-ethnicity
extension:tribalAffiliation		0..*	(Complex)	(USCDI) Tribal Affiliation Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-tribal-affiliation
extension:birthsex		0..1	code	Birth Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-birthsex Binding: Birth Sex (required): Code for sex assigned at birth
extension:sex		0..1	code	(USCDI) Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-sex Binding: Sex (required): Concepts limited to Male, Female, Patient Sex Unknown, asked-declined.
extension:genderIdentity		0..*	CodeableConcept	(USCDI) The individual's gender identity URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-genderIdentity Binding: Gender Identity (extensible)
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
identifier	SΣ	1..*	Identifier	(USCDI) An identifier for this patient
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
use	?!SΣ	0..1	code	usual | official | temp | secondary | old (If known) Binding: IdentifierUse (required): Identifies the purpose for this identifier, if known .
type	SΣ	0..1	CodeableConcept	Description of identifier Binding: Identifier Type Codes (extensible): A coded type for an identifier that can be used to determine which identifier to use for a specific purpose.
system	SΣ	1..1	uri	(USCDI) The namespace for the identifier value Example General: http://www.acme.com/identifiers/patient
value	SΣ	1..1	string	(USCDI) The value that is unique within the system. Example General: 123456
period	SΣ	0..1	Period	Time period when id is/was valid for use
assigner	Σ	0..1	Reference(Organization)	Organization that issued id (may be just text)
active	?!Σ	0..1	boolean	Whether this patient's record is in active use
name	SΣC	1..*	HumanName	(USCDI) A name associated with the patient Constraints: us-core-6
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
use	?!SΣ	0..1	code	(USCDI) usual | official | temp | nickname | anonymous | old | maiden Binding: NameUse (required): The use of a human name.
text	SΣ	0..1	string	Text representation of the full name
family	SΣC	0..1	string	(USCDI) Family name (often called 'Surname')
given	SΣC	0..*	string	(USCDI) Given names (not always 'first'). Includes middle names This repeating element order: Given Names appear in the correct order for presenting the name
prefix	SΣ	0..*	string	Parts that come before the name This repeating element order: Prefixes appear in the correct order for presenting the name
suffix	SΣ	0..*	string	(USCDI) Parts that come after the name This repeating element order: Suffixes appear in the correct order for presenting the name
period	SΣ	0..1	Period	(USCDI) Time period when name was/is in use
telecom	Σ	0..*	ContactPoint	(USCDI) A contact detail for the individual
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
system	SΣC	1..1	code	(USCDI) phone | fax | email | pager | url | sms | other Binding: ContactPointSystem (required): Telecommunications form for contact point.
value	SΣ	1..1	string	(USCDI) The actual contact point details
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | mobile - purpose of this contact point Binding: ContactPointUse (required)
rank	SΣ	0..1	positiveInt	Specify preferred order of use (1 = highest)
period	SΣ	0..1	Period	Time period when the contact point was/is in use
gender	SΣ	1..1	code	(USCDI) male | female | other | unknown Binding: AdministrativeGender (required)
birthDate	SΣ	1..1	date	(USCDI) The date of birth for the individual
deceased[x]	?!SΣ	0..1		(USCDI) Indicates if the individual is deceased or not
deceasedBoolean			boolean
deceasedDateTime			dateTime
address	SΣ	0..*	Address	(USCDI) An address for the individual
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | billing - purpose of this address Binding: AddressUse (required): The use of an address. Example General: home
type	SΣ	0..1	code	postal | physical | both Binding: AddressType (required): The type of an address (physical / postal). Example General: both
text	SΣ	0..1	string	Text representation of the address Example General: 137 Nowhere Street, Erewhon 9132
line	SΣ	0..*	string	(USCDI) Street name, number, direction & P.O. Box etc. This repeating element order: The order in which lines should appear in an address label Example General: 137 Nowhere Street
city	SΣ	0..1	string	(USCDI) Name of city, town etc. Example General: Erewhon
district	SΣ	0..1	string	District name (aka county) Example General: Madison
state	SΣ	0..1	string	(USCDI) Sub-unit of country (abbreviations ok) Binding: UspsTwoLetterAlphabeticCodes (6.1.0) (extensible): Two Letter USPS alphabetic codes.
postalCode	SΣ	0..1	string	(USCDI) US Zip Codes Example General: 9132
country	SΣ	0..1	string	Country (e.g. can be ISO 3166 2 or 3 letter code)
period	Σ	0..1	Period	(USCDI) Time period when address was/is in use Example General: {"start":"2010-03-23","end":"2010-07-01"}
maritalStatus		0..1	CodeableConcept	Marital (civil) status of a patient Binding: Marital Status Codes (extensible): The domestic partnership status of a person.
multipleBirth[x]		0..1		Whether patient is part of a multiple birth
multipleBirthBoolean			boolean
multipleBirthInteger			integer
photo		0..*	Attachment	Image of the patient
contact	SC	0..*	BackboneElement	A contact party (e.g. guardian, partner, friend) for the patient Constraints: pat-1
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
relationship	S	0..*	CodeableConcept	The kind of relationship Binding: PatientContactRelationship (extensible): The nature of the relationship between a patient and a contact person for that patient.
name	S	0..1	HumanName	A name associated with the contact person
telecom		0..*	ContactPoint	A contact detail for the person
address	S	0..1	Address	Address for the contact person
gender		0..1	code	male | female | other | unknown Binding: AdministrativeGender (required): The gender of a person used for administrative purposes.
organization	C	0..1	Reference(Organization)	Organization that is associated with the contact
period	S	0..1	Period	The period during which this contact person or organization is valid to be contacted relating to this patient
communication		0..*	BackboneElement	(USCDI) A language which may be used to communicate with the patient about his or her health
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
language	S	1..1	CodeableConcept	(USCDI) The language which can be used to communicate with the patient about his or her health Binding: LanguageCodesWithLanguageAndOptionallyARegionModifier (6.1.0) (extensible)
preferred	S	0..1	boolean	Language preference indicator
generalPractitioner		0..*	Reference(Organization | Practitioner | PractitionerRole)	Patient's nominated primary care provider
managingOrganization	Σ	0..1	Reference(Organization)	Organization that is the custodian of the patient record
link	?!SΣ	0..*	BackboneElement	Link to another patient resource that concerns the same actual person
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
other	Σ	1..1	Reference(Patient | RelatedPerson)	The other patient or related person resource that the link refers to
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
reference	ΣC	1..1	string	Literal reference, Relative, internal or absolute URL
type	Σ	0..1	uri	Type the reference refers to (e.g. "Patient") Binding: ResourceType (extensible): Aa resource (or, for logical models, the URI of the logical model).
identifier	Σ	0..1	Identifier	Logical reference, when literal reference is not known
display	Σ	0..1	string	Text alternative for the resource
type	Σ	1..1	code	replaced-by | replaces | refer | seealso Binding: LinkType (required): The type of link between this patient resource and another patient resource.
Documentation for this format

Terminology Bindings

Path	Conformance	ValueSet	URI
Patient.meta.security	extensible	All Security Labels http://hl7.org/fhir/ValueSet/security-labels|4.0.1 From the FHIR Standard
Patient.meta.tag	example	CommonTags http://hl7.org/fhir/ValueSet/common-tags|4.0.1 From the FHIR Standard
Patient.language	preferred	CommonLanguages http://hl7.org/fhir/ValueSet/languages From the FHIR Standard Additional Bindings Purpose AllLanguages Max Binding
Patient.identifier.use	required	IdentifierUse http://hl7.org/fhir/ValueSet/identifier-use|4.0.1 From the FHIR Standard
Patient.identifier.type	extensible	Identifier Type Codes http://hl7.org/fhir/ValueSet/identifier-type From the FHIR Standard
Patient.name.use	required	NameUse http://hl7.org/fhir/ValueSet/name-use|4.0.1 From the FHIR Standard
Patient.telecom.system	required	ContactPointSystem http://hl7.org/fhir/ValueSet/contact-point-system From the FHIR Standard
Patient.telecom.use	required	ContactPointUse http://hl7.org/fhir/ValueSet/contact-point-use From the FHIR Standard
Patient.gender	required	AdministrativeGender http://hl7.org/fhir/ValueSet/administrative-gender From the FHIR Standard
Patient.address.use	required	AddressUse http://hl7.org/fhir/ValueSet/address-use|4.0.1 From the FHIR Standard
Patient.address.type	required	AddressType http://hl7.org/fhir/ValueSet/address-type|4.0.1 From the FHIR Standard
Patient.address.state	extensible	UspsTwoLetterAlphabeticCodes http://hl7.org/fhir/us/core/ValueSet/us-core-usps-state|6.1.0
Patient.maritalStatus	extensible	Marital Status Codes http://hl7.org/fhir/ValueSet/marital-status From the FHIR Standard
Patient.contact.relationship	extensible	PatientContactRelationship http://hl7.org/fhir/ValueSet/patient-contactrelationship From the FHIR Standard
Patient.contact.gender	required	AdministrativeGender http://hl7.org/fhir/ValueSet/administrative-gender|4.0.1 From the FHIR Standard
Patient.communication.language	extensible	LanguageCodesWithLanguageAndOptionallyARegionModifier http://hl7.org/fhir/us/core/ValueSet/simple-language|6.1.0
Patient.link.other.type	extensible	ResourceType http://hl7.org/fhir/ValueSet/resource-types|4.0.1 From the FHIR Standard
Patient.link.type	required	LinkType http://hl7.org/fhir/ValueSet/link-type|4.0.1 From the FHIR Standard

Constraints

Id	Grade	Path(s)	Details	Requirements
dom-2	error	Patient	If the resource is contained in another resource, it SHALL NOT contain nested Resources : contained.contained.empty()
dom-3	error	Patient	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource : contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Patient	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated : contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Patient	If a resource is contained in another resource, it SHALL NOT have a security label : contained.meta.security.empty()
dom-6	best practice	Patient	A resource should have narrative for robust management : text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children : hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both : extension.exists() != value.exists()
pat-1	error	Patient.contact	SHALL at least contain a contact's details or a reference to an organization : name.exists() or telecom.exists() or address.exists() or organization.exists()
us-core-6	error	Patient.name	At least name.given and/or name.family are present or, if neither is available, the Data Absent Reason Extension is present. : (family.exists() or given.exists()) xor extension.where(url='http://hl7.org/fhir/StructureDefinition/data-absent-reason').exists()

This structure is derived from USCorePatientProfile

Summary

Mandatory: 2 elements(1 nested mandatory element)
Must-Support: 23 elements

Extensions

This structure refers to these extensions:

• http://www.cdc.gov/nhsn/fhirportal/dqm/ig/StructureDefinition/link-received-date-extension

Maturity: 1

Key Elements View

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Patient		0..*	USCorePatientProfile(6.1.0)	Information about an individual or animal receiving health care services
id	Σ	1..1	id	Logical id of this artifact
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
Slices for extension				Content/Rules for all slices
extension:race		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-race
extension:ethnicity		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-ethnicity
extension:tribalAffiliation		0..*	(Complex)	(USCDI) Tribal Affiliation Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-tribal-affiliation
extension:birthsex		0..1	code	Birth Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-birthsex Binding: Birth Sex (required): Code for sex assigned at birth
extension:sex		0..1	code	(USCDI) Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-sex Binding: Sex (required): Concepts limited to Male, Female, Patient Sex Unknown, asked-declined.
extension:genderIdentity		0..*	CodeableConcept	(USCDI) The individual's gender identity URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-genderIdentity Binding: Gender Identity (extensible)
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
identifier	SΣ	1..*	Identifier	(USCDI) An identifier for this patient
use	?!SΣ	0..1	code	usual | official | temp | secondary | old (If known) Binding: IdentifierUse (required): Identifies the purpose for this identifier, if known .
type	SΣ	0..1	CodeableConcept	Description of identifier Binding: Identifier Type Codes (extensible): A coded type for an identifier that can be used to determine which identifier to use for a specific purpose.
system	SΣ	1..1	uri	(USCDI) The namespace for the identifier value Example General: http://www.acme.com/identifiers/patient
value	SΣ	1..1	string	(USCDI) The value that is unique within the system. Example General: 123456
period	SΣ	0..1	Period	Time period when id is/was valid for use
active	?!Σ	0..1	boolean	Whether this patient's record is in active use
name	SΣC	1..*	HumanName	(USCDI) A name associated with the patient Constraints: us-core-6
use	?!SΣ	0..1	code	(USCDI) usual | official | temp | nickname | anonymous | old | maiden Binding: NameUse (required): The use of a human name.
text	SΣ	0..1	string	Text representation of the full name
family	SΣC	0..1	string	(USCDI) Family name (often called 'Surname')
given	SΣC	0..*	string	(USCDI) Given names (not always 'first'). Includes middle names This repeating element order: Given Names appear in the correct order for presenting the name
prefix	SΣ	0..*	string	Parts that come before the name This repeating element order: Prefixes appear in the correct order for presenting the name
suffix	SΣ	0..*	string	(USCDI) Parts that come after the name This repeating element order: Suffixes appear in the correct order for presenting the name
period	SΣ	0..1	Period	(USCDI) Time period when name was/is in use
telecom	Σ	0..*	ContactPoint	(USCDI) A contact detail for the individual
system	SΣC	1..1	code	(USCDI) phone | fax | email | pager | url | sms | other Binding: ContactPointSystem (required): Telecommunications form for contact point.
value	SΣ	1..1	string	(USCDI) The actual contact point details
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | mobile - purpose of this contact point Binding: ContactPointUse (required)
rank	SΣ	0..1	positiveInt	Specify preferred order of use (1 = highest)
period	SΣ	0..1	Period	Time period when the contact point was/is in use
gender	SΣ	1..1	code	(USCDI) male | female | other | unknown Binding: AdministrativeGender (required)
birthDate	SΣ	1..1	date	(USCDI) The date of birth for the individual
deceased[x]	?!SΣ	0..1		(USCDI) Indicates if the individual is deceased or not
deceasedBoolean			boolean
deceasedDateTime			dateTime
address	SΣ	0..*	Address	(USCDI) An address for the individual
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | billing - purpose of this address Binding: AddressUse (required): The use of an address. Example General: home
type	SΣ	0..1	code	postal | physical | both Binding: AddressType (required): The type of an address (physical / postal). Example General: both
text	SΣ	0..1	string	Text representation of the address Example General: 137 Nowhere Street, Erewhon 9132
line	SΣ	0..*	string	(USCDI) Street name, number, direction & P.O. Box etc. This repeating element order: The order in which lines should appear in an address label Example General: 137 Nowhere Street
city	SΣ	0..1	string	(USCDI) Name of city, town etc. Example General: Erewhon
district	SΣ	0..1	string	District name (aka county) Example General: Madison
state	SΣ	0..1	string	(USCDI) Sub-unit of country (abbreviations ok) Binding: UspsTwoLetterAlphabeticCodes (6.1.0) (extensible): Two Letter USPS alphabetic codes.
postalCode	SΣ	0..1	string	(USCDI) US Zip Codes Example General: 9132
country	SΣ	0..1	string	Country (e.g. can be ISO 3166 2 or 3 letter code)
contact	SC	0..*	BackboneElement	A contact party (e.g. guardian, partner, friend) for the patient Constraints: pat-1
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
relationship	S	0..*	CodeableConcept	The kind of relationship Binding: PatientContactRelationship (extensible): The nature of the relationship between a patient and a contact person for that patient.
name	S	0..1	HumanName	A name associated with the contact person
address	S	0..1	Address	Address for the contact person
period	S	0..1	Period	The period during which this contact person or organization is valid to be contacted relating to this patient
communication		0..*	BackboneElement	(USCDI) A language which may be used to communicate with the patient about his or her health
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
language	S	1..1	CodeableConcept	(USCDI) The language which can be used to communicate with the patient about his or her health Binding: LanguageCodesWithLanguageAndOptionallyARegionModifier (6.1.0) (extensible)
preferred	S	0..1	boolean	Language preference indicator
link	?!SΣ	0..*	BackboneElement	Link to another patient resource that concerns the same actual person
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
other	Σ	1..1	Reference(Patient | RelatedPerson)	The other patient or related person resource that the link refers to
reference	ΣC	1..1	string	Literal reference, Relative, internal or absolute URL
type	Σ	1..1	code	replaced-by | replaces | refer | seealso Binding: LinkType (required): The type of link between this patient resource and another patient resource.
Documentation for this format

Terminology Bindings

Path	Conformance	ValueSet	URI
Patient.identifier.use	required	IdentifierUse http://hl7.org/fhir/ValueSet/identifier-use|4.0.1 From the FHIR Standard
Patient.identifier.type	extensible	Identifier Type Codes http://hl7.org/fhir/ValueSet/identifier-type From the FHIR Standard
Patient.name.use	required	NameUse http://hl7.org/fhir/ValueSet/name-use|4.0.1 From the FHIR Standard
Patient.telecom.system	required	ContactPointSystem http://hl7.org/fhir/ValueSet/contact-point-system From the FHIR Standard
Patient.telecom.use	required	ContactPointUse http://hl7.org/fhir/ValueSet/contact-point-use From the FHIR Standard
Patient.gender	required	AdministrativeGender http://hl7.org/fhir/ValueSet/administrative-gender From the FHIR Standard
Patient.address.use	required	AddressUse http://hl7.org/fhir/ValueSet/address-use|4.0.1 From the FHIR Standard
Patient.address.type	required	AddressType http://hl7.org/fhir/ValueSet/address-type|4.0.1 From the FHIR Standard
Patient.address.state	extensible	UspsTwoLetterAlphabeticCodes http://hl7.org/fhir/us/core/ValueSet/us-core-usps-state|6.1.0
Patient.contact.relationship	extensible	PatientContactRelationship http://hl7.org/fhir/ValueSet/patient-contactrelationship From the FHIR Standard
Patient.communication.language	extensible	LanguageCodesWithLanguageAndOptionallyARegionModifier http://hl7.org/fhir/us/core/ValueSet/simple-language|6.1.0
Patient.link.type	required	LinkType http://hl7.org/fhir/ValueSet/link-type|4.0.1 From the FHIR Standard

Constraints

Id	Grade	Path(s)	Details	Requirements
dom-2	error	Patient	If the resource is contained in another resource, it SHALL NOT contain nested Resources : contained.contained.empty()
dom-3	error	Patient	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource : contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Patient	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated : contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Patient	If a resource is contained in another resource, it SHALL NOT have a security label : contained.meta.security.empty()
dom-6	best practice	Patient	A resource should have narrative for robust management : text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children : hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both : extension.exists() != value.exists()
pat-1	error	Patient.contact	SHALL at least contain a contact's details or a reference to an organization : name.exists() or telecom.exists() or address.exists() or organization.exists()
us-core-6	error	Patient.name	At least name.given and/or name.family are present or, if neither is available, the Data Absent Reason Extension is present. : (family.exists() or given.exists()) xor extension.where(url='http://hl7.org/fhir/StructureDefinition/data-absent-reason').exists()

Differential View

This structure is derived from USCorePatientProfile

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Patient		0..*	USCorePatientProfile(6.1.0)	Information about an individual or animal receiving health care services
id		1..1	id	Logical id of this artifact
meta
Slices for extension				Content/Rules for all slices
extension:link-received-date-extension		0..1	dateTime	Received Date URL: http://www.cdc.gov/nhsn/fhirportal/dqm/ig/StructureDefinition/link-received-date-extension
Slices for extension				Content/Rules for all slices
extension:race		0..1	USCoreRaceExtension(6.1.0)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.)
extension:ethnicity		0..1	USCoreEthnicityExtension(6.1.0)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.)
identifier
use	S	0..1	code	usual | official | temp | secondary | old (If known)
type	S	0..1	CodeableConcept	Description of identifier
period	S	0..1	Period	Time period when id is/was valid for use
name
use	S	0..1	code	(USCDI) usual | official | temp | nickname | anonymous | old | maiden
text	S	0..1	string	Text representation of the full name
prefix	S	0..*	string	Parts that come before the name
suffix	S	0..*	string	(USCDI) Parts that come after the name
period	S	0..1	Period	(USCDI) Time period when name was/is in use
telecom
rank	S	0..1	positiveInt	Specify preferred order of use (1 = highest)
period	S	0..1	Period	Time period when the contact point was/is in use
birthDate		1..1	date	(USCDI) The date of birth for the individual
deceased[x]	S	0..1	boolean, dateTime	(USCDI) Indicates if the individual is deceased or not
address
use	S	0..1	code	(USCDI) home | work | temp | old | billing - purpose of this address
type	S	0..1	code	postal | physical | both
text	S	0..1	string	Text representation of the address
district	S	0..1	string	District name (aka county)
country	S	0..1	string	Country (e.g. can be ISO 3166 2 or 3 letter code)
contact	S	0..*	BackboneElement	A contact party (e.g. guardian, partner, friend) for the patient
relationship	S	0..*	CodeableConcept	The kind of relationship
name	S	0..1	HumanName	A name associated with the contact person
address	S	0..1	Address	Address for the contact person
period	S	0..1	Period	The period during which this contact person or organization is valid to be contacted relating to this patient
communication
preferred	S	0..1	boolean	Language preference indicator
link	S	0..*	BackboneElement	Link to another patient resource that concerns the same actual person
other
reference		1..1	string	Literal reference, Relative, internal or absolute URL
Documentation for this format

Snapshot View

Name	Flags	Card.	Type	Description & Constraints    Filter: Bindings Constraints Obligations
Patient		0..*	USCorePatientProfile(6.1.0)	Information about an individual or animal receiving health care services
id	Σ	1..1	id	Logical id of this artifact
meta	Σ	0..1	Meta	Metadata about the resource
id		0..1	string	Unique id for inter-element referencing
Slices for extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
extension:link-received-date-extension		0..1	dateTime	Received Date URL: http://www.cdc.gov/nhsn/fhirportal/dqm/ig/StructureDefinition/link-received-date-extension
versionId	Σ	0..1	id	Version specific identifier
lastUpdated	Σ	0..1	instant	When the resource version last changed
source	Σ	0..1	uri	Identifies where the resource comes from
profile	Σ	0..*	canonical(StructureDefinition)	Profiles this resource claims to conform to
security	Σ	0..*	Coding	Security Labels applied to this resource Binding: All Security Labels (extensible): Security Labels from the Healthcare Privacy and Security Classification System.
tag	Σ	0..*	Coding	Tags applied to this resource Binding: CommonTags (example): Codes that represent various types of tags, commonly workflow-related; e.g. "Needs review by Dr. Jones".
implicitRules	?!Σ	0..1	uri	A set of rules under which this content was created
language		0..1	code	Language of the resource content Binding: CommonLanguages (preferred): A human language. Additional Bindings Purpose AllLanguages Max Binding
text		0..1	Narrative	Text summary of the resource, for human interpretation This profile does not constrain the narrative in regard to content, language, or traceability to data elements
contained		0..*	Resource	Contained, inline Resources
Slices for extension		0..*	Extension	Extension Slice: Unordered, Open by value:url
extension:race		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-race
extension:ethnicity		0..1	(Complex)	US Core Race Extension (If present, must include at least one of the required codes. Preferably this would include at least a code in the ombCategory slice.) URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-ethnicity
extension:tribalAffiliation		0..*	(Complex)	(USCDI) Tribal Affiliation Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-tribal-affiliation
extension:birthsex		0..1	code	Birth Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-birthsex Binding: Birth Sex (required): Code for sex assigned at birth
extension:sex		0..1	code	(USCDI) Sex Extension URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-sex Binding: Sex (required): Concepts limited to Male, Female, Patient Sex Unknown, asked-declined.
extension:genderIdentity		0..*	CodeableConcept	(USCDI) The individual's gender identity URL: http://hl7.org/fhir/us/core/StructureDefinition/us-core-genderIdentity Binding: Gender Identity (extensible)
modifierExtension	?!	0..*	Extension	Extensions that cannot be ignored
identifier	SΣ	1..*	Identifier	(USCDI) An identifier for this patient
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
use	?!SΣ	0..1	code	usual | official | temp | secondary | old (If known) Binding: IdentifierUse (required): Identifies the purpose for this identifier, if known .
type	SΣ	0..1	CodeableConcept	Description of identifier Binding: Identifier Type Codes (extensible): A coded type for an identifier that can be used to determine which identifier to use for a specific purpose.
system	SΣ	1..1	uri	(USCDI) The namespace for the identifier value Example General: http://www.acme.com/identifiers/patient
value	SΣ	1..1	string	(USCDI) The value that is unique within the system. Example General: 123456
period	SΣ	0..1	Period	Time period when id is/was valid for use
assigner	Σ	0..1	Reference(Organization)	Organization that issued id (may be just text)
active	?!Σ	0..1	boolean	Whether this patient's record is in active use
name	SΣC	1..*	HumanName	(USCDI) A name associated with the patient Constraints: us-core-6
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
use	?!SΣ	0..1	code	(USCDI) usual | official | temp | nickname | anonymous | old | maiden Binding: NameUse (required): The use of a human name.
text	SΣ	0..1	string	Text representation of the full name
family	SΣC	0..1	string	(USCDI) Family name (often called 'Surname')
given	SΣC	0..*	string	(USCDI) Given names (not always 'first'). Includes middle names This repeating element order: Given Names appear in the correct order for presenting the name
prefix	SΣ	0..*	string	Parts that come before the name This repeating element order: Prefixes appear in the correct order for presenting the name
suffix	SΣ	0..*	string	(USCDI) Parts that come after the name This repeating element order: Suffixes appear in the correct order for presenting the name
period	SΣ	0..1	Period	(USCDI) Time period when name was/is in use
telecom	Σ	0..*	ContactPoint	(USCDI) A contact detail for the individual
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
system	SΣC	1..1	code	(USCDI) phone | fax | email | pager | url | sms | other Binding: ContactPointSystem (required): Telecommunications form for contact point.
value	SΣ	1..1	string	(USCDI) The actual contact point details
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | mobile - purpose of this contact point Binding: ContactPointUse (required)
rank	SΣ	0..1	positiveInt	Specify preferred order of use (1 = highest)
period	SΣ	0..1	Period	Time period when the contact point was/is in use
gender	SΣ	1..1	code	(USCDI) male | female | other | unknown Binding: AdministrativeGender (required)
birthDate	SΣ	1..1	date	(USCDI) The date of birth for the individual
deceased[x]	?!SΣ	0..1		(USCDI) Indicates if the individual is deceased or not
deceasedBoolean			boolean
deceasedDateTime			dateTime
address	SΣ	0..*	Address	(USCDI) An address for the individual
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
use	?!SΣ	0..1	code	(USCDI) home | work | temp | old | billing - purpose of this address Binding: AddressUse (required): The use of an address. Example General: home
type	SΣ	0..1	code	postal | physical | both Binding: AddressType (required): The type of an address (physical / postal). Example General: both
text	SΣ	0..1	string	Text representation of the address Example General: 137 Nowhere Street, Erewhon 9132
line	SΣ	0..*	string	(USCDI) Street name, number, direction & P.O. Box etc. This repeating element order: The order in which lines should appear in an address label Example General: 137 Nowhere Street
city	SΣ	0..1	string	(USCDI) Name of city, town etc. Example General: Erewhon
district	SΣ	0..1	string	District name (aka county) Example General: Madison
state	SΣ	0..1	string	(USCDI) Sub-unit of country (abbreviations ok) Binding: UspsTwoLetterAlphabeticCodes (6.1.0) (extensible): Two Letter USPS alphabetic codes.
postalCode	SΣ	0..1	string	(USCDI) US Zip Codes Example General: 9132
country	SΣ	0..1	string	Country (e.g. can be ISO 3166 2 or 3 letter code)
period	Σ	0..1	Period	(USCDI) Time period when address was/is in use Example General: {"start":"2010-03-23","end":"2010-07-01"}
maritalStatus		0..1	CodeableConcept	Marital (civil) status of a patient Binding: Marital Status Codes (extensible): The domestic partnership status of a person.
multipleBirth[x]		0..1		Whether patient is part of a multiple birth
multipleBirthBoolean			boolean
multipleBirthInteger			integer
photo		0..*	Attachment	Image of the patient
contact	SC	0..*	BackboneElement	A contact party (e.g. guardian, partner, friend) for the patient Constraints: pat-1
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
relationship	S	0..*	CodeableConcept	The kind of relationship Binding: PatientContactRelationship (extensible): The nature of the relationship between a patient and a contact person for that patient.
name	S	0..1	HumanName	A name associated with the contact person
telecom		0..*	ContactPoint	A contact detail for the person
address	S	0..1	Address	Address for the contact person
gender		0..1	code	male | female | other | unknown Binding: AdministrativeGender (required): The gender of a person used for administrative purposes.
organization	C	0..1	Reference(Organization)	Organization that is associated with the contact
period	S	0..1	Period	The period during which this contact person or organization is valid to be contacted relating to this patient
communication		0..*	BackboneElement	(USCDI) A language which may be used to communicate with the patient about his or her health
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
language	S	1..1	CodeableConcept	(USCDI) The language which can be used to communicate with the patient about his or her health Binding: LanguageCodesWithLanguageAndOptionallyARegionModifier (6.1.0) (extensible)
preferred	S	0..1	boolean	Language preference indicator
generalPractitioner		0..*	Reference(Organization | Practitioner | PractitionerRole)	Patient's nominated primary care provider
managingOrganization	Σ	0..1	Reference(Organization)	Organization that is the custodian of the patient record
link	?!SΣ	0..*	BackboneElement	Link to another patient resource that concerns the same actual person
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations
modifierExtension	?!Σ	0..*	Extension	Extensions that cannot be ignored even if unrecognized
other	Σ	1..1	Reference(Patient | RelatedPerson)	The other patient or related person resource that the link refers to
id		0..1	string	Unique id for inter-element referencing
extension		0..*	Extension	Additional content defined by implementations Slice: Unordered, Open by value:url
reference	ΣC	1..1	string	Literal reference, Relative, internal or absolute URL
type	Σ	0..1	uri	Type the reference refers to (e.g. "Patient") Binding: ResourceType (extensible): Aa resource (or, for logical models, the URI of the logical model).
identifier	Σ	0..1	Identifier	Logical reference, when literal reference is not known
display	Σ	0..1	string	Text alternative for the resource
type	Σ	1..1	code	replaced-by | replaces | refer | seealso Binding: LinkType (required): The type of link between this patient resource and another patient resource.
Documentation for this format

Terminology Bindings

Path	Conformance	ValueSet	URI
Patient.meta.security	extensible	All Security Labels http://hl7.org/fhir/ValueSet/security-labels|4.0.1 From the FHIR Standard
Patient.meta.tag	example	CommonTags http://hl7.org/fhir/ValueSet/common-tags|4.0.1 From the FHIR Standard
Patient.language	preferred	CommonLanguages http://hl7.org/fhir/ValueSet/languages From the FHIR Standard Additional Bindings Purpose AllLanguages Max Binding
Patient.identifier.use	required	IdentifierUse http://hl7.org/fhir/ValueSet/identifier-use|4.0.1 From the FHIR Standard
Patient.identifier.type	extensible	Identifier Type Codes http://hl7.org/fhir/ValueSet/identifier-type From the FHIR Standard
Patient.name.use	required	NameUse http://hl7.org/fhir/ValueSet/name-use|4.0.1 From the FHIR Standard
Patient.telecom.system	required	ContactPointSystem http://hl7.org/fhir/ValueSet/contact-point-system From the FHIR Standard
Patient.telecom.use	required	ContactPointUse http://hl7.org/fhir/ValueSet/contact-point-use From the FHIR Standard
Patient.gender	required	AdministrativeGender http://hl7.org/fhir/ValueSet/administrative-gender From the FHIR Standard
Patient.address.use	required	AddressUse http://hl7.org/fhir/ValueSet/address-use|4.0.1 From the FHIR Standard
Patient.address.type	required	AddressType http://hl7.org/fhir/ValueSet/address-type|4.0.1 From the FHIR Standard
Patient.address.state	extensible	UspsTwoLetterAlphabeticCodes http://hl7.org/fhir/us/core/ValueSet/us-core-usps-state|6.1.0
Patient.maritalStatus	extensible	Marital Status Codes http://hl7.org/fhir/ValueSet/marital-status From the FHIR Standard
Patient.contact.relationship	extensible	PatientContactRelationship http://hl7.org/fhir/ValueSet/patient-contactrelationship From the FHIR Standard
Patient.contact.gender	required	AdministrativeGender http://hl7.org/fhir/ValueSet/administrative-gender|4.0.1 From the FHIR Standard
Patient.communication.language	extensible	LanguageCodesWithLanguageAndOptionallyARegionModifier http://hl7.org/fhir/us/core/ValueSet/simple-language|6.1.0
Patient.link.other.type	extensible	ResourceType http://hl7.org/fhir/ValueSet/resource-types|4.0.1 From the FHIR Standard
Patient.link.type	required	LinkType http://hl7.org/fhir/ValueSet/link-type|4.0.1 From the FHIR Standard

Constraints

Id	Grade	Path(s)	Details	Requirements
dom-2	error	Patient	If the resource is contained in another resource, it SHALL NOT contain nested Resources : contained.contained.empty()
dom-3	error	Patient	If the resource is contained in another resource, it SHALL be referred to from elsewhere in the resource or SHALL refer to the containing resource : contained.where((('#'+id in (%resource.descendants().reference | %resource.descendants().as(canonical) | %resource.descendants().as(uri) | %resource.descendants().as(url))) or descendants().where(reference = '#').exists() or descendants().where(as(canonical) = '#').exists() or descendants().where(as(canonical) = '#').exists()).not()).trace('unmatched', id).empty()
dom-4	error	Patient	If a resource is contained in another resource, it SHALL NOT have a meta.versionId or a meta.lastUpdated : contained.meta.versionId.empty() and contained.meta.lastUpdated.empty()
dom-5	error	Patient	If a resource is contained in another resource, it SHALL NOT have a security label : contained.meta.security.empty()
dom-6	best practice	Patient	A resource should have narrative for robust management : text.`div`.exists()
ele-1	error	**ALL** elements	All FHIR elements must have a @value or children : hasValue() or (children().count() > id.count())
ext-1	error	**ALL** extensions	Must have either extensions or value[x], not both : extension.exists() != value.exists()
pat-1	error	Patient.contact	SHALL at least contain a contact's details or a reference to an organization : name.exists() or telecom.exists() or address.exists() or organization.exists()
us-core-6	error	Patient.name	At least name.given and/or name.family are present or, if neither is available, the Data Absent Reason Extension is present. : (family.exists() or given.exists()) xor extension.where(url='http://hl7.org/fhir/StructureDefinition/data-absent-reason').exists()

This structure is derived from USCorePatientProfile

Summary

Mandatory: 2 elements(1 nested mandatory element)
Must-Support: 23 elements

Extensions

This structure refers to these extensions:

• http://www.cdc.gov/nhsn/fhirportal/dqm/ig/StructureDefinition/link-received-date-extension

Maturity: 1
